Product Overview: Robust and durable high-pressure fluid control solution

Our high-pressure ball valves are specifically designed for demanding (demanding) industrial applications and can provide outstanding shut-off performance in harsh high-pressure environments. This valve is manufactured with precise engineering design and high-quality materials, ensuring reliable and long-lasting service in key fields such as oil and gas, chemical processing, power and energy. Its core advantages lie in excellent structural integrity, low-torque operation and extremely low leakage rate, making it an ideal choice for your high-pressure pipeline system.

Core features and advantages

Outstanding high-voltage load-bearing capacity

It adopts high-strength valve body materials (such as forged carbon steel, stainless steel, etc.) and reinforced structural design, which can safely and stably withstand extremely high system pressure.

Reliable sealing performance

Advanced sealing materials (such as PTFE and metal seals) are adopted to ensure bidirectional zero leakage even under high-pressure conditions. The sealing parts have been optimized in design, featuring excellent compressive resistance and a long service life.

Low operating torque and flexible opening and closing

Even under high pressure, the precisely machined combination of the ball and the valve seat can ensure flexible opening and closing with a small operating torque. It can be equipped with pneumatic, electric or hydraulic actuators to easily achieve automated control.

A sturdy and durable structure

The valve stem anti-blowout design ensures safety when the valve cavity is under pressure. The one-piece or bolt-connected valve body structure offers higher structural strength and integrity.

Wide adaptability to media and temperatures

It is applicable to water, oil products, steam, natural gas, various corrosive chemicals and other harsh media. Depending on the material and sealing selection, it can adapt to a wide temperature range from low to high.

Easy to maintain

The modular design and replaceable valve seat sealing system make maintenance and part replacement quick and easy, minimizing downtime.

Technical specifications

Valve type: Floating ball valve or trunnion mounted ball valve

Nominal diameter: 1/4" to 12" (DN 8 to DN 300)

Pressure rating: ANSI Class 600, 900, 1500, 2500 or PN 100, 160, 250, 420

Valve body materials: carbon steel (A105/WCB), stainless steel (304/316), duplex steel, alloy steel, etc

Connection methods: threaded, flanged, butt welding, socket welding

Operation modes: manual (handle/gearbox), pneumatic, electric, hydraulic

Temperature range: Depending on the sealing material, usually from -50°C to above +200°C

Typical applications

Petroleum and natural gas: wellhead equipment, pipeline transportation, refining and chemical equipment

Chemical Engineering and Petrochemical Industry: High-pressure reactors, process pipelines, catalyst injection

Electric power industry: boiler feed water, steam pipes, soot blowing systems

Industrial equipment: high-pressure water jet, hydraulic system, compressed air system

Quality assurance

Each of our high-pressure ball valves is strictly produced and manufactured in accordance with the ISO 9001 quality management system standards, and passes a series of strict tests, including pressure tests, sealing tests and performance tests, to ensure the absolute reliability of the products before leaving the factory.
