Pneumatic V-Port Ball Valve - Product Description

Overview: A Precision Solution for Advanced Flow Control

Our Pneumatic V-Port Ball Valve is an engineered control valve designed for applications requiring precise modulation and superior control of various media, including slurries, powders, and viscous fluids. Unlike standard on/off ball valves, its characterized V-notch ball and advanced pneumatic actuation make it the ideal choice for demanding processes in industries such as chemical processing, pulp & paper, power generation, and wastewater treatment.

Key Features & Benefits:

• Precise Flow Control & Characterization
  The core of the valve is the precision-machined V-notch ball. This design provides an accurate, linear flow characteristic that is nearly proportional to the stroke, allowing for excellent control and stability, especially in throttling applications.

• Shearing Action & Anti-Clogging Design
  The sharp-edged V-ball shears through fibrous materials and semi-solids during rotation, effectively preventing clogging and ensuring reliable operation in handling slurries, pulp, and other challenging media.

• High Capacity & Rangeability
  The optimized flow passage offers high capacity and exceptional rangeability, meaning the valve can maintain precise control over a wide range of flow rates, from low to full capacity.

• Robust & Long-Lasting Construction

  • Actuator: The pneumatic actuator is manufactured from extruded aluminum alloy and undergoes a hard-anodized surface treatment for exceptional corrosion resistance and durability.

  • Wear-Resistant Support: All moving parts are supported by wear-resistant materials, significantly extending the service life and reducing maintenance needs.

  • Stem & Sealing: A robust stem design and high-performance sealing materials (such as PTFE, RPTFE, or Metal Seated options) ensure tight shut-off and minimal fugitive emissions.

• Bidirectional Shut-Off
  The valve provides reliable, bubble-tight shut-off in both flow directions, enhancing system safety and integrity.

Technical Specifications:

• Valve Type: V-Port Ball Valve

• Actuation: Pneumatic (Double-Acting or Spring-Return)

• Ball Design: V-notch (Available in various angles: 15°, 30°, 45°, 60°, 90°)

• Body Materials: Carbon Steel, Stainless Steel 304/316, Duplex Stainless Steel, and other alloys.

• Seat Materials: PTFE, Reinforced PTFE (RPTFE), PPL, Metal

• End Connections: Flanged (ANSI, DIN, JIS, etc.), Threaded (NPT, BSP)

• Pressure Rating: ANSI 150# to 600#, PN16 to PN100, or as required.

• Temperature Range: -29°C to +450°F (-20°C to +232°C), depending on seat material.

• Accessories: Positioners, Limit Switches, Solenoid Valves, Filter Regulators, etc.

Applications:

This valve is ideally suited for:

• Chemical Industry: Controlling acids, alkalis, and solvents.

• Pulp & Paper: Regulating pulp stock and chemical additives.

• Power Generation: Fly ash slurry, FGD systems.

• Water & Wastewater: Sludge, lime slurry, and chemical dosing.

• Mining & Minerals: Abrasive and corrosive slurry lines.

Why Choose Hengli?

Jinhua Hengli Valve Co., Ltd. is a high-tech enterprise dedicated to providing innovative fluid control solutions. Our Pneumatic V-Port Ball Valves are manufactured under strict ISO9001 quality standards using high-precision CNC equipment. We are committed to delivering products with superior performance, reliability, and cost-effectiveness.

Contact us today to discuss your specific application needs and discover how our Pneumatic V-Port Ball Valve can optimize your process control.
